These instructions apply to the Toyota Aygo Mk1 (B10) 2005-2014.
For other models, please choose your vehicle here.
Full specifications for the Toyota Aygo (B10, first generation), covering the 1.0 VVT-i (1KR-FE) petrol that made up almost every car sold. Figures are compiled from the Toyota owner’s manual and this car’s own door tire placard, cross-checked against published EU data; confirm anything critical against your own vehicle’s papers.
Each column is one specific vehicle — a single engine or motor and, where shown, body style. Dimensions and several weights are specific to that body and drivetrain; other body or powertrain versions differ, so match the column to your own vehicle.
| 1.0 VVT-i (1KR-FE) HatchbackEU | |
|---|---|
| Length | 3,405 mm |
| Width (excl. mirrors) | 1,615 mm |
| Height | 1,465 mm |
| Wheelbase | 2,340 mm |
| Track (front / rear) | — |
| 1.0 VVT-i (1KR-FE) HatchbackEU | |
|---|---|
| Kerb weight | 775 kg |
| Gross vehicle weight | 1,190 kg |
| Payload (approx.) | 415 kg |
| Max axle load, front | 695 kg |
| Max axle load, rear | 695 kg |
| Towing (braked trailer) | Not rated for towing |
| 1.0 VVT-i (1KR-FE) HatchbackEU | |
|---|---|
| Engine code | 1KR-FE |
| Fuel | Petrol |
| Cylinders / layout | 3, in line (12 valves) |
| Displacement | 998 cc |
| Max power | 50 kW (68 PS) @ 6,000 |
| Max torque | 93 Nm @ 3,600 |
| Aspiration | — |
| Emission standard | Euro 4 |
| 1.0 VVT-i (1KR-FE) HatchbackEU | |
|---|---|
| 0–100 km/h (0–60 mph) | — |
| Top speed | 157 km/h (98 mph) |
| Drive | Front-wheel drive |
| Transmission | 5-speed manual (MultiMode automated manual optional) |
| 1.0 VVT-i (1KR-FE) HatchbackEU | |
|---|---|
| Fuel consumption (combined) | 4.6 l/100km (NEDC) |
| Urban / extra-urban | 5.5 / 4.1 l/100km (NEDC) |
| CO₂ (combined) | 109 g/km (NEDC) |
| Fuel tank | 35 litres |
| Drive-by noise | — |
| 1.0 VVT-i (1KR-FE) HatchbackEU | |
|---|---|
| Front brakes | — |
| Rear brakes | — |
| Tyre sizes | 155/65 R14 75T |
| Rim sizes | — |
| Tyre pressures, normal (front / rear) | 2.2 bar / 32 psi (155/65 R14, front & rear, up to 160 km/h) |
| Tyre pressures, laden (front / rear) | 2.3 bar / 34 psi (front & rear, sustained speeds above 160 km/h) |
| Wheel-nut torque | — |
| 1.0 VVT-i (1KR-FE) HatchbackEU | |
|---|---|
| Engine oil (with filter) | 3.3 L with filter (3.1 L without) · 0W-20 (5W-30 if 0W-20 unavailable) |
| Coolant | Toyota Super Long Life Coolant (pink, hybrid organic acid) |
| Gearbox oil (manual) | — |
| 12 V battery | — |
| Air-con refrigerant | — |
| Spark plugs | — |
| Spark-plug gap | — |
Sources: Owner's manual. Where an owner’s manual or homologation figure exists it takes precedence; workshop data fills only what those omit.
A dash (—) means we haven’t yet verified that figure, not that it doesn’t exist. Each column shows that market’s own figures on its own test standard.
Frequently Asked Questions
What are the tire pressures for a Toyota Aygo?
On the standard 155/65 R14 tires, Toyota specifies 2.2 bar (32 psi) front and rear for normal use, rising to 2.3 bar (34 psi) only for sustained speeds above 160 km/h. Always set them cold and check the label on your own door pillar.
How much does a Toyota Aygo weigh?
Kerb weight is about 775 kg, with a gross vehicle weight limit of 1,190 kg — so a payload of roughly 415 kg including passengers and luggage.
How big is the Aygo fuel tank?
The fuel tank holds 35 litres of unleaded (95 RON). With official combined economy around 4.6 l/100km, that gives a long real-world range for such a small car.
What engine oil does the Aygo 1.0 take?
About 3.3 litres with a new filter (3.1 litres without). Toyota fills 0W-20 at the factory; 5W-30 may be used if 0W-20 is not available.
Can a Toyota Aygo tow a trailer?
No. The Aygo Mk1 is not rated for towing — its gross train weight equals its gross vehicle weight, so no braked or unbraced trailer is approved.
Disclaimer: Figures are typical for the generation and may vary by market, trim and options. Always confirm critical figures (weights, towing, tire sizes) against your own vehicle’s documents.
