Set the Wipers to Service Position

To change the blades or clear snow on your Renault Kadjar (XFE, 2015–2022) you need the wipers in their upright service position. Park them normally and they sit tucked under the bonnet lip out of reach — here’s how to stand them up safely.

The service position — sometimes called the maintenance or winter position — raises both front wiper arms high off the windscreen so you can get behind them. On the Kadjar you reach for it in two everyday situations: renewing the blades once they smear or judder, and standing the arms up in cold weather so they do not freeze flat to the glass overnight and tear the rubber when you first switch them on. It is a designed-in feature of the car, not a fault, and the arms will only rise when you trigger the mode the right way.

Why There’s a Service Position

The Kadjar parks its wiper arms low against the scuttle, tucked under the lip of the bonnet where they sit out of the airflow. That low park is exactly why you should not simply grab an arm and swing it up — the blade catches on the bonnet edge, and levering it strains the wiper linkage and can crack the plastic trim. The service mode gets round that by first sweeping the arms up to a clear rest point where nothing is in the way, so you can then fold them off the glass without a fight.

First, a Few Checks

• Make sure the bonnet is fully closed — the mode will not arm with it open.
• Set the ignition as the steps describe; the timing after switch-off matters.
• If the blades are frozen to the screen, free them gently first — lifting against ice can stall the motor.
• Have the new blades unpacked and ready so the arms are not left standing longer than needed.
• Work one arm at a time, keeping a hand on any arm that could spring back onto the glass.

Raising the Wipers

1. Make sure the bonnet is closed and the wipers are parked.
2. Switch the ignition on, then off.
3. Within a few seconds, push the wiper stalk down (the single-wipe position) briefly.
4. The arms sweep up and hold clear of the screen.
5. Fold them away from the glass to change blades or clear ice.

Returning Them

When you have finished, lay each arm back down onto the screen — do not drive off with them standing. Then switch the ignition on and operate the wipers once; they sweep and drop back to the parked position under the bonnet lip by themselves. If an arm does not settle exactly at park, one more full wipe cycle usually seats it.

Won’t Lift?

• Too slow — the stalk only triggers it for a few seconds after ignition-off; try the sequence again more promptly.
• Wrong ignition state — you need the on-then-off sequence, not the engine running.
• Bonnet not latched — close it fully and retry; a bonnet that is not quite shut blocks the mode.
• Blades frozen down — free them from the ice first, then repeat.
• Wipers weren’t parked — let them return to their normal rest point before you start.

Changing the Blades

With the arms standing clear, support the arm with one hand so it cannot spring back — a bare metal arm dropping onto the screen can crack it. Most Kadjar blades use a common clip or hook fitting: release the catch, slide the old blade off, and click the new one on until it locks home. Fit the fresh blade, then lower the arm gently by hand rather than letting it snap down, and do both sides before you send the wipers back to park.

Frequently Asked Questions

How do I put Renault Kadjar wipers in service position?

With the bonnet closed and the wipers parked, switch the ignition on then off, and within a few seconds push the wiper stalk down (the single-wipe position). The arms sweep up and stand off the glass.

Any tools needed?

None. The service position is set with the wiper stalk alone. Swapping the blades is a hand job as well — the clip or hook fitting releases without tools.

How do I get them back down?

Fold each arm flat onto the screen, switch the ignition on, and run the wipers once. They sweep and re-park under the bonnet lip on their own. Never leave the arms standing when you drive off.

Can I just lift the arms at park without the service mode?

Better not to. At park the arms sit below the bonnet line, so pulling one straight up fouls the bonnet edge and strains the linkage. Use the service position and the arm rises clear first.

Why won’t my Kadjar enter the service position?

The usual causes are a bonnet that is not fully latched, being too slow after ignition-off, or blades frozen to the glass. Close the bonnet firmly, free any ice, and repeat the on-off-then-stalk sequence promptly.

Does using the service position reset anything?

No. It only moves the wiper arms — it does not clear service reminders, fault codes, or any settings. It is purely a mechanical convenience for changing blades or lifting the arms in frost.
