Reset the TPMS

Last updated: May 18, 2026

The second-generation Nissan Qashqai (J11 chassis, 2014–2021 — also sold as the Rogue Sport in the US) is fitted with a Tyre Pressure Monitoring System on every UK/EU trim. The Qashqai uses a direct TPMS — each wheel has a valve-stem transmitter that reports pressure to the body computer over a low-power radio link. After inflating tyres, rotating wheels, or replacing a sensor, the system needs a short drive to re-learn and an optional manual reset via the steering-wheel menu.

Before you start

The Qashqai’s direct TPMS measures actual pressure in each tyre and displays per-wheel values on the cluster’s information display. The system maps each sensor’s unique ID to a physical wheel position automatically during driving (via the receiver’s signal-strength differentiation), so a swap of two wheels is detected within a few minutes.

• Always check pressures cold. The car must have been stationary at least 3 hours or driven less than 1 km. Warm tyres read higher than their true cold value and produce a baseline that’s wrong once the car cools.
• Driver’s door-jamb placard. The OEM cold pressures are on a sticker in the driver’s door pillar — typically 2.2 bar / 32 psi on standard 17″ wheels, with full-load and high-speed alternative values listed below the normal-load row.
• Accurate gauge required. Forecourt gauges drift over time. A £15 dial gauge or £25 digital gauge is far more reliable.
• Don’t reset before inflating. The reset confirms the system has accepted the new pressures — running it first baselines the under-inflated state.

Tools required

• Accurate tyre pressure gauge
• Compressor or foot pump (a calibrated forecourt machine is fine)

When to reset the TPMS

• After inflating any of the four tyres to the correct cold pressure.
• After replacing a tyre or fitting new wheels.
• After rotating tyres front-to-back.
• After a battery disconnect that takes more than a few seconds.
• After replacing a TPMS sensor (sensors typically last 7–10 years before the internal battery fails).

Reset procedure

1. Inflate all four tyres cold to the placard pressures, verified with your own gauge.
2. Switch the ignition ON by pressing the START button once without your foot on the brake pedal. The dashboard illuminates; the engine remains off.
3. Use the steering-wheel arrow buttons (left and right on the four-way pad below the cluster) to scroll the central information display until “Tyre Pressure” or “Tyre Pressure Monitor” appears.
4. Press OK (the centre button) to enter the TPMS menu. The display now shows the current four-wheel pressure values.
5. Press and hold OK for approximately 3 seconds — until “Reset complete” or “Pressures set” appears. The system has now committed the current pressures as the baseline.
6. Start the engine and drive normally for at least 5 minutes at 25 km/h or above.
7. The TPMS warning light extinguishes once each sensor has reported its new pressure within the acceptable range. Direct TPMS doesn’t strictly need the reset (it’ll self-learn during the drive) but the manual reset clears the previous baseline immediately.

How to verify it has worked

• The TPMS warning light is no longer illuminated on the cluster.
• Scrolling back to the “Tyre Pressure” menu shows four per-wheel pressure values, all within ±0.1 bar of what you set.
• No “Check Tyre Pressure” text message appears at start-up the next morning.

Troubleshooting

One specific wheel shows “—” or “Sensor not detected”. The valve-stem sensor on that wheel has failed — most likely the internal battery (sensors are rated for 7–10 years on the J11). Replacement requires a tyre dismount and rebalance. Cost is around £40–60 per sensor at most independent tyre shops; OEM Nissan sensors are part number 40700 4CB0A.

The warning light flashes for 60 seconds at every start, then stays solid. This is the “system fault” signal, not a low-pressure warning. It means the TPMS module has logged a stored fault, most often “lost communication with one or more sensors”. Scan the body module with a Nissan-aware tool (CONSULT III+ or aftermarket equivalents like Carista with Nissan subscription).

I changed to a different wheel size — TPMS won’t accept the new baseline. Different tyre size means different rolling circumference, which the J11’s TPMS uses as part of its plausibility check. Reset cold with the new pressures and drive 30 minutes — the system rebases. If still no luck, the wheel size needs entering in the user-settings menu (some J11 trims expose this; others lock it behind dealer programming).

Warning returned 24 hours after the reset. Slow puncture on one tyre. The per-wheel display will pinpoint which tyre is losing pressure — recheck cold the next morning and look for the offending tyre. Common locations: nail in the tread, slow valve-core leak, or bead leak (a film of soapy water around each tyre’s bead will bubble at the leak point).

“TPMS” appears with no specific message. The system is in fault state from a stored body-module code that won’t clear automatically. A scan with the right tool is needed. Don’t ignore this — direct TPMS in fault state means the protection is not functional.

Frequently asked questions

Does the Rogue Sport (US-market J11) use the same procedure?
Yes — Qashqai J11 and Rogue Sport are the same car with different badging. The TPMS reset procedure is identical. The cluster’s menu labels may differ slightly in the US English variant (“Tire” instead of “Tyre”, “psi” rather than “bar”) but the navigation is the same.

How long do TPMS sensors last?
The internal battery in each Qashqai J11 sensor is rated for 7–10 years. By 2024 onwards, many original J11 sensors are reaching end-of-life. Replacement is best done in pairs (both fronts or both rears) since they typically fail within months of each other once the first goes.

Does cold weather cause false TPMS warnings?
Yes. Tyre pressure drops approximately 0.1 bar per 10 °C cool-down. The first cold morning of autumn often triggers the warning on a car set to summer placard pressures. Top up to placard cold and run the reset.

Should I reset after rotating tyres front-to-back?
Not strictly necessary on direct TPMS — the sensors continue to report their wheel’s actual pressure regardless of position. The system will detect that “front-left” is now reading what “rear-left” used to and adjust within a few minutes of driving. Optionally you can run the reset to speed up the position relearn.

Will the system warn me about a fully flat tyre, or only gradual deflation?
Both — a sudden complete deflation (puncture) shows up within seconds and triggers an audible chime + warning lamp. Gradual deflation is also caught, usually within 30 seconds to a few minutes depending on the rate.

For TPMS-related diagnostic trouble codes that won’t clear with a drive cycle, see autodtcs.com.
