These instructions apply to the Toyota Yaris Cross Mk1 (XP21) 2021-Present. For other models, please choose your vehicle here.
Last updated:
A weak smart key is the usual reason a Toyota Yaris Cross (XP21, 2021–present) stops locking from a distance or shows a “key battery low” message. The fob takes one coin cell and you can change it in a couple of minutes.
Battery You Need
The Yaris Cross smart key uses a CR2032 3 V coin cell. Check the cell you remove and match it.
How to Replace the Key Battery
- Push and hold the release and slide out the mechanical key.
- Insert a small screwdriver into the slot (tape the tip to avoid marks) and separate the two cases.
- Lift out the old CR2032, noting the orientation — don’t touch the terminals.
- Fit the new cell with the positive (+) side facing up.
- Clip the cases back together and slide the mechanical key home.
Lock and unlock from a few metres to confirm; the fob LED should flash when a button is pressed.
If It Still Won’t Work
- Start the car anyway — touch the smart key to the start button as you press it; the car reads the transponder directly.
- Lock/unlock manually with the mechanical key.
Frequently Asked Questions
What battery does the Toyota Yaris Cross key take?
A single CR2032 3 V coin cell, positive side up.
Do I need to reprogram the key after changing the battery?
No — only adding a new key needs dealer programming.
How do I open the Yaris Cross smart key?
Slide out the mechanical key, then separate the cases with a taped screwdriver.
My key still won’t start the car — what now?
Hold the key against the start button as you press it.
For a no-start with a warning light, check the code on autodtcs.com. See also our Yaris Cross battery guide if the car is dead.
